Features:
Compact and durable design
Easy to use software
3 channel, 5 lead cable
Up to 7 day holter
Continuous recording – full disclosure
Pacemaker detection
Multiple software solutions – Silver, Gold & Platinum
Specification:
Leads: 5
Resolution: 12 bit, stored at 8-bit MSB
Sample Rate: 24000 sps per channel oversampling, stored at 256 sps
Frequency Response: 0.05- Hz (3dB)
Gain Settings: 0.25, 0.5, 1, 2 & 4 x
Signal Verification: LCD display, ECG waveform during hookup
Pacemaker Detection: concurrent pacemaker detection on all channels, Programmable on/off
Defibrillator Protection: None, must be removed before defibrillation
User Operation: 5 button keypad + event button
Data Transfer: Direct USB connection
Dimensions: 64.8×50.8×12.7mm
Power Source: 1 X AAA alkaline or 1.5v lithium battery
Battery Life: Up to 4 days for alkaline & 7 days for lithium
Weight: 41 gm with battery
Operating Conditions: 5-45 degrees celsius, 10-95% humidity (non condensing), 70Kpa to 106Kpa atmospheric temp
Kit Inclusions: Universal Smart ECG, QRS Resting ECG Tab Electrodes PK100, Sure-Lock snap & tab electrode adaptors PK10, Lead Placement Guide, Office Medic Software
Warranty: 2 Years
ORDER CODES:
VECZ702008
MAINTENANCE: Please make sure your ECG is serviced & calibration check is completed yearly to ensure it functions to its optimum.
